A Ubiquiti Networks projetou os primeiros rádios airMAX® ac para alto desempenho e facilidade de instalação. Você tem a liberdade de implantar o Rocket® ac em qualquer lugar do mundo e isso permite um alto grau de flexibilidade na configuração das larguras de banda do canal (sujeito aos regulamentos locais do país). Emparelhe o Rocket5ac Lite com antenas airMAX ac para um desempenho ideal:
– PtP backhaul Rocket5ac Lite com o RocketDish ™ ac
– PtMP conecta Rocket5ac Lite com o setor airMAX ac
Características:
– Banda de frequência de 5 GHz
– Gigabit Ethernet
– Power over Ethernet (PoE) passivo
– Potência de saída
– Integração Plug and Play
| Dimensions |
162 x 84 x 37 mm
(6.4 x 3.3 x 1.5″) |
| Weight |
250 g
(8.82 oz) |
| Networking Interface |
(1) 10/100/1000 Ethernet Port |
| RF Connectors |
(2) RP-SMA (Waterproof) |
| LEDs |
Power, LAN, (4) Signal Strength |
| Enclosure |
Outdoor UV Stabilized Plastic |
| Max. Power Consumption |
8.5W |
| Power Supply |
24V, 0.5A Gigabit PoE Adapter (Included) |
| Power Method |
Passive PoE (Pairs 4, 5+; 7, 8 Return) |
| Operating Temperature |
-40 to 80° C (-40 to 176° F) |
| Operating Humidity |
5 to 95% Noncondensing |
| ESD/EMP Protection |
± 24kV Contact / Air for Ethernet |
| Shock and Vibration |
ETSI300-019-1.4 |
| Certifications |
CE, FCC, IC |
| Worldwide |
5150 – 5875 |
US/CA
U-NII-1
U-NII-2A
U-NII-2C
U-NII-3 |
5150 – 5250
5250 – 5350
5470 – 5725
5725 – 5850 |
