Construa e expanda sua rede com o switch UniFi®, parte do sistema Ubiquiti Networks® UniFi Enterprise. O UniFi Switch 48 500W é um switch PoE + Gigabit totalmente gerenciado, oferecendo desempenho robusto e comutação inteligente para redes corporativas. O UniFi Switch 48 500W oferece 48 portas de detecção automática IEEE 802.3af / at ou PoE 24 V configurável para simplificar sua infraestrutura. Além disso, duas portas SFP + e duas portas SFP fornecem opções de uplink e conectividade de fibra capazes de fornecer velocidades de até 10 Gbps.
Características:
– (48) Portas Ethernet Gigabit RJ45
– Detecção automática IEEE 802.3af / em PoE +
– PoE passivo de 24 V configurável
– (2) Portas SFP 1G
– (2) portas 10G SFP +
– Fonte de alimentação 500W
– Gerenciado por UniFi Controller
– Altura de montagem em rack 1U
| US-48-500W |
| Dimensions |
485 x 43.7 x 374.6 mm
(19.09 x 1.72 x 14.75″) |
| Weight |
6.1 kg
(13.5 lb) |
| Networking Interfaces |
((48) 10/100/1000 Mbps RJ45 Ethernet Ports
(2) 1/10 Gbps SFP+ Ethernet Ports
(2) 1 Gbps SFP Ethernet Ports |
| Management Interface |
(1) RJ45 Serial Port Out-of-Band, Ethernet In-Band |
| Total Non-Blocking Throughput |
70 Gbps |
| Switching Capacity |
140 Gbps |
| Forwarding Rate |
104.16 Mpps |
| MAC Address Table |
16384 |
| Maximum Aggregations |
6 |
| Monitoring Sessions |
1 |
| Maximum VLANs |
255 |
| Power Method |
100-240VAC/50-60 Hz, Universal Input |
| Power Supply |
AC/DC, Internal, 500W DC |
Max. Power Consumption
Including PoE Output
Excluding PoE Output |
500W
64W |
LEDs Per Port
RJ45 Data Ports
SFP Data Ports |
PoE, Speed/Link/Activity
Speed/Link/Activity |
Sound Level*
Fan Level 0
Fan Level 1
Fan Level 2
Fan Level 3 |
10.7 dBr
16.2 dBr
19.3 dBr
23.6 dBr |
| ESD/EMP Protection |
Air: ± 24 kV, Contact: ± 24 kV |
| Shock and Vibration |
ETSI300-019-1.4 Standard |
| Operating Temperature |
-5 to 40° C (23 to 104° F) |
| Operating Humidity |
5 to 95% Noncondensing |
| Certifications |
CE, FCC, IC |
| POE+ PER PORT |
| PoE Interfaces |
PoE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6- )
24VDC Passive PoE (Pins 4, 5+; 7, 8- ) |
| Max. PoE+ Wattage per Port by PSE |
34.2W |
| Voltage Range 802.3at Mode |
50–57V |
| Max. Passive PoE Wattage per Port |
17W |
| 24V Passive PoE Voltage Range |
20-27V |
* Background noise level: 27.5 dBa
